Views: 17 Author: migrand machinery Publish Time: 2025-09-04 Origin: Migrand machinery
This machine is suitable for applying labels to one side, two sides, three sides, or all four sides of square bottled products in industries such as food, condiments, pharmaceuticals, liquor, oils, cosmetics, and others.
The machine features a ingenious design, eliminating unnecessary mechanical complexity and bulkiness. Its modular assembly allows for maintenance and repairs without requiring specialized personnel. When changing products, simple adjustments are sufficient to resume production immediately.
The entire machine is constructed from stainless steel and high-grade aluminum alloy.
The labeling head is driven by a high-quality stepper motor.
All sensors are high-grade photoelectric sensors from Japan and Germany.
Controlled by a PLC with a large Human-Machine Interface (HMI).
Suitable for small batch, high variety production; operates as a single unit by one person.
Incorporates mechanisms for bottle alignment, bottle separation, labeling, label smoothing, and counting.
Can be connected to a conveyor belt for integration into production lines.
| Parameter | Specification |
|---|---|
| Power Supply Voltage (V/Hz) | AC 220/50 or 110/60 |
| Total Power Consumption (W) | 1500 |
| Labeling Accuracy (mm) | ±1.0 |
| Applicable Label Range (mm) | Height 20-100mm, Length 20-300mm |
| Applicable Product Range (mm) | Outer Diameter 20-100mm, Height 30-200mm |
| Output (bottles/minute) | 20-40 (Specific speed depends on product and label size) |
| Overall Dimensions (L×W×H)(mm) | 2000×860×1550 |
| Net Weight (kg) | 300 |
| Component | Origin | Brand |
|---|---|---|
| PLC | Germany | Siemens |
| Touch Screen (HMI) | Germany | Siemens |
| Motor | China | Leadshine |
| Label Sensor | Germany | Sick |
| Pneumatic Components | Taiwan | Airtac |
| Frequency Converter | Guangzhou | Keken |
