CGN208D1 Semi Automatic Capsule Filling Machine
Home » Products » Capsule Filling Machine » Semi Automatic Capsule Filling Machine » CGN208D1 Semi Automatic Capsule Filling Machine


CGN208D1 Semi Automatic Capsule Filling Machine

Share to:
Mobile/Wechat/Whatsapp: +86-13787413551

Introduction of semi-automatic CGN208D1 capsule filling machine

CGN208-D1 type capsule filling machine is a new efficientequipment based on DTJ-C model (old type) after researchand development: easier more intuitive and higher loadingin capsule dropping, U-turning, vacuum separation incomparison with the old type. The new type of capsuleorientating adopts columns pill positioning design, whichshortens the time in the replacement of mould from theoriginal 30 minutes to 5-8 minutes.The level type automaticlocking device (patent design) improves the efficiency ofthe lock capsule and reduces the labor intensity of the workers.

This machine is one type of electricity and pneumatic combinedcontrol,automatic counting electronics, programmablecontroller and frequency conversion speed regulating device.Instead of manual filling, it reduces labor intensity, whichis the ideal equipment for capsule filling for small and medium-sized pharmaceutical companies, pharmaceutical researchand development institutions and hospital preparation room.

Semi automatic capsule filler Application

The product is special capsule filling machine  Semi Automatic Capsule Filling Machine | Capsule Filler which is suitable for medium and small pharmaceutical factory, hospital preparation lab, etc. The capsule filler is adopted programmable control system, touch panel operation, step-less transudation speed-shift, and electronic automatic counter. Capsule filling machine semi automatic can automatic complete the action of position, separation, filling, locking, etc. The dosage is accurate, and the operation is convenient. The overall capsule filler is made of stainless steel, and it is suitable for the capsule which is filled with powder and grain.

Main Features

1) High quality hard gelatin semi auto capsule filling machine is controlled by step-less frequency conversion and pneumatic device, and adopts electronic counter.

2) High quality hard gelatin semi auto capsule filling machine can finish position, separation, filling, locking of capsule, and reduce the labor intensity and improve working efficiency.

3) Control : Siemens PLC and touch screen control.

Main Technical Parameters
Semi Automatic Capsule Filling Machine
Machine model
Max. Output(A set of mold)
12000-18000 Capsules/hour
20000 – 25000pcs/hour
Capsule Size
Dosage Type
Power Supply
380V±10%, 50/60Hz, 3ph
Net:400KG Gross:500KG
Net:480KG Gross:580KG
Machine Size
1200*700*1650 mm
1140*700*1600 mm
Packing Size
1650*720*1700 mm
1400*860*1500 mm
