GDL20
MIGRAND
8422303090
| Availability: | |
|---|---|
|
| |
Applicability: Suitable for pouch packaging in the daily chemical and food industries, such as laundry detergent, shampoo, jelly, milk, etc.
User-Friendly Operation: Digital parameter adjustment; saved settings for similar pouches require only capacity adjustment.
High Efficiency: Fast filling speed with excellent stability. Each filling volume is independently controlled by a servo motor for high precision.
Easy Cleaning: Gear pumps, storage tanks, and filling heads feature clamp-type connections for tool-free disassembly and localized cleaning. An automatic cleaning button is integrated into the main control panel.
| Model | GDL20 | GDL02 |
| Filling volume(g) | 50～5000g | 50～3000g |
| Packaging speed | 10～70pouchs/min | 10～35pouchs/min |
| Filling pump | Gear pump, piston pump, rotor pump,etc | |
| Packaging capacity range | ±0.5% | |
| Power | 220V/50HZ，3.2KW | 220V/50HZ，2KW |
| Oxygen consumption | 0.5-0.8Mpa，1.5m³/min； | 0.5-0.8Mpa，0.5m³/min |
| Equipment size | 1200x1200x1500 | 800x900x700 |
| Weight | 270Kg | 60kg |
| Function | Manual pouch hanging-automatic filling-manual cap feed/vibration cap feed-automatic capping; | |
