Powder Bottle Filling Capping Machine

This is a powder bottling production line comprising a bottle unscrambler, a dual-head powder filling machine, a vibrating cap feeder, and a capping machine. Depending on specific requirements, additional equipment—such as a bottle washer, labeling machine, or cartoning machine—can also be added.

. Equipment Overview

The linear powder filling machine is primarily used for powder bottle packaging in pharmaceutical, food, and chemical industries. It features a fully sealed design with stainless steel and acrylic material bins combined with servo-controlled filling screws, linear conveyor belt positioning systems, and pneumatic bottle blocking mechanisms. This equipment offers advantages such as easy dosage adjustment, simple operation, and quick bin disassembly for cleaning. It can operate independently or be integrated into production lines with upstream and downstream equipment. Optional protective covers are available, and the number of filling hoppers can be customized according to production capacity requirements.

II. Technical Parameters

III. Structural Characteristics

1. The frame section is constructed using welded 50×50×4mm 45# steel square tubes, with tabletop panels fabricated from high-quality carbon steel sheets through laser processing. The carbon steel components employ a baked paint coating technique, while the entire exterior surface is protected with 304 stainless steel plates.

2、The system adopts a dual powder head dispensing structure with cylinder-based positioning and bottle interception. Powder materials can be equipped with feeding devices as required, such as vacuum feeders or screw feeders.

IV. Configuration Form
