DCHK series
MIGRAND
| Availability: | |
|---|---|
|
| |
Characteristics
1) No staple design. Knot technology to connect tag and filter teabag. A hygeian, environmental and shapely packaging solution.
2)Adaptable for various materials, doses adjustable, gauge accuracy ±5%.
3) Equipped with damping and tension system, transferring rolls stablely.
5) Lubricated by a centralized lubrication system, timely and quantitatively lubricating the machine, running smoothly.
6) Filter bags are counted, grouped and outputed, optional feature of manual/automatic cartoning.
7)Advanced control system and multi-servo system, stable running with low noise.
8) Intelligent HMI supports multiple languages with friendly interface, easy to operate.
9) Safety protections for leakage, short circuit, overload, etc.
Technological innovation:
High qualification rate: solve the problem of wrong sealing;
High stability: servo drive, PLC control, sensor detection, stable and reliable;
Good-looking envelope: cutting device of envelope bag edge is optional;
Intelligent: remote control, etc.
Technical Data
| DCHK 20 (double chamber) | DCKKYJ 10 (double chamber) | DCHF 21 (single chamber) | DCHF 20 (single chamber) | DCHF 11 (single chamber) | |
| Capacity | 150±10bags/min | 120±10bags/min | 110±5bags/min | 110±5bags/min | 130-1505bags/min |
| Max.Dosage | 13 cm³ (adjustable) | 10 cm³ (adjustable) | 6 cm³ | 10 cm³ | 6 cm³ |
| Degree of accuracy | ±5% | ±5% | ±5% | ±5% | ±3% |
| Bag dimensions (L×W) | 45mm×60mm or40mm×60mm | 45mm×60mm or40mm×60mm | 50mm×62 .5 mm | 65mm×62 .5 mm | 50mm×62.5mm |
| Tag dimensions(L×W) | 28mm×32mm | 28mm×32mm | 28 mm×24 mm | 28 mm×24 mm | 24mm ×28mm |
| Envelope dimensions(L×W) | 70mm×80mm | 148mm±5mm | 70mm×80 mm | ||
| Thread length | 210mm±5mm | 13mm (5mm after folding) | 210mm | 220mm | 210±5 mm |
| Group of teabags | 25bags/group; 15~30bags/group adjustable | ||||
| Air pressure | 0.6MPa | 0.6MPa | 0.6MPa | 0.6MPa | 0.6MPa |
| Air consumption | 400L/min | 300L/min | 300L/min | 300L/min | 300L/min |
| Voltage | 3 phases 380V 50 HZ | 3 phases 220V/3 phases 380V | AC 380V/220V | AC 380V/220V | AC 380V/220V, 50HZ/60HZ |
| Power | 4.5 kW | 10kW | 3 kW | 3 kW | ≤1.5KW |
| Overall dimension(LxWxH) | 2400×1735×2800mm | 3500×1500×2400mm | 2.840m×1 .222m×2 .250m | 2.840m×1 .222m×2 .250m | 1.7m ×0 .9m × 2.2m |
| Net Weight | 4000kg | 4000kg | 1410kg | 1410kg | 750KG |
| Gross weight | 4250kg | 4250kg | 1610kg | 1610kg | 860KG |
| Wooden case dimension | 2800×1950×2000mm | 2900×1950×2000mm | 2.140m×1 .410m×1 .890m | 2.140m×1 .410m×1 .890m | 1.32m × 1.140m×2 .0m |
Options:
Pneumatic vacuum feeder
Date printer
Vibratory feeder device
Heatseal tag device
